EasyDock®
Weld-on connector for onshore and offshore medium service severity applications. Robust, quick and easy to operate with high back-off resistance and no need of torque-turn graphs. An optimized solution to complete well architecture.
EasyDock®
Easy make-up
Visual make-up reference, pre-installed anti-rotational keys, internal and external self-alignment guides for easy stabbing.
Efficient and fast running
Proprietary BTC modified crest-to-root thread profile with 3 thread starts and fast thread taper for easy stabbing.
Sealability and performance
Internal elastomeric seal pre-installed at the mill guarantees liquid sealability. Double shoulder provides high compression and bending capacity.
Quick and robust connector
The TenarisHydril EasyDock® connector is designed for medium severity conditions typical of shallow waters. A solid thread technology allows it to be safe, robust, quick and easy to operate, with no need for special installation tools. With high structural capacity, the EasyDock® connector provides a liquid-tight seal validated under API RP 5C5.
Tenaris manufactures connectors under the same quality management system as pipes, and can supply them as part of a more extensive casing and tubing package for offshore wells.
This complete solution is backed by Tenaris's global service network providing technical assistance, product testing, pipe management and technical support in the field.
Features
- Sizes 24" - 36"
- Fast and safe make up with minimum cross threading risk
- Allows multiple make-and-break's without damage
- Pre-installed anti-rotational keys for extra assurance against connector accidental buck-off.
- Lifting shoulder on box side compatible with side-door and single-joint elevators
- Suitable for driving installation
- Liquid tightness under combined load conditions, validated under API RP 5C5
EasyDock® connector
